LaTeX links
Contents
Links ↩
One of the advantages of working with LaTeX is the possibility of referencing different parts of your document without worrying if they change their page in the future.
A label id is declared by invoking a simple command \label{key}
. Now you can reference it by calling \ref{key}
and get its current page with \pageref{key}
.
Label declaration:
\chapter{Chapter}
\section{Section}
\label{my_label}
Label referencing:
See section \ref{my_label} on page \pageref{my_label}.
Which will produce something like See section 2.1 on page 9.
nameref
The nameref
package1 provides a single command \nameref
that prints out the name of the object (e.g. the section's title) being referenced.
cleveref
The cleveref
package2 provides some additional commands, including \cref
and \cpageref
which automatically detect the type of link being referenced.
The code below will produce the same output without manually writing "section" or "page" in the text.
See \cref{my_label} on \cpageref{my_label}.
varioref
The \vref
command of the varioref
package3 simplifies the process even more, allowing you to write:
See section \vref{my_label}.
Moreover, the command is aware of the proximity of the link being referenced, changing the output accordingly:
- ref to this page:
See section 2.2.
- ref to the previous page:
See section 1.1 on the previous page.
- ref to the next page:
See section 3.1 on the next page.
- ref to the distant page:
See section 4.2 on page 11.
fancyref
Additional customization of the reference output is possible with the fancyref
package4, but you will need to prefix your links properly with \label{sec:my_label}
(for the link to the section, for example).
See \fref{sec:my_label}.
\Fref{sec:my_label} --- capitalized reference.
Here's the list of pre-defined prefixes:
- Chapter:
chap
- Section:
sec
- Equation:
eq
- Figure:
fig
- Table:
tab
- Enumeration:
enum
- Footnote:
fn
You can define your own prefixes (or re-define the existing ones) by following the instructions given in the package's documentation, e.g.:
\newcommand*{\fancyrefmaplabelprefix}{map}
\fancyrefaddcaptions{english}{
\providecommand*{\frefmapname}{map}
\providecommand*{\Frefmapname}{Map}
}
\frefformat{plain}{\fancyrefmaplabelprefix}{\frefmapname\fancyrefdefaultspacing#1}
\Frefformat{plain}{\fancyrefmaplabelprefix}{\Frefmapname\fancyrefdefaultspacing#1}
\frefformat{vario}{\fancyrefmaplabelprefix}{\frefmapname\fancyrefdefaultspacing#1#3}
\Frefformat{vario}{\fancyrefmaplabelprefix}{\Frefmapname\fancyrefdefaultspacing#1#3}
And now your \fref{map:my_map}
and \Fref{map:my_map}
references to the \label{map:my_map}
will print out map 2.1 on page 10
or Map 2.1 on page 10
accordingly.
Hyperlinks ↩
And, finally, let's make all of these links clickable. We are making a PDF after all!
You can easily achieve this by loading the hyperref
package5, which will hyperlink all of your references. This includes not only the ones made with nameref
, cleveref
, varioref
, or fancyref
packages, but even your table of contents and lists of tables and figures.
The package provides some additional commands to create custom-named references to links, such as \hyperref[label]{text}
that works similarly to \ref{label}
. Linking to an arbitrary text is also possible with a pair of \hypertarget{name}{text}
and \hyperlink{name}{text}
commands, the latter pointing to the former. Note that the text
argument in the \hypertarget
command can be empty.
And, of course, you can create URLs:
\url{https://vladar.bearblog.dev/}
\href{https://vladar.bearblog.dev/}{blog}
The default styling of the links (red rectangles) is not very aesthetically pleasing but can be changed by setting some options in the \hypersetup
command.
\hypersetup{
pdfborderstyle={/S/U/W 1},% underlined links
linkbordercolor={0 0.5 0},% dark green links
urlbordercolor={0 0.5 0.5}% teal URL links
}
As you can see, the colors are declared as RGB values in the 0
to 1
range. The border style definition is more cryptic and requires studying the PDF specification's6 section 12.5.4 "Border Styles". In brief, the following keys are supported by most PDF viewers:
/S
— border style, followed by:/S
— solid rectangle,/D
— dashed rectangle,/U
— underline;
/D
— (for dashed rectangles only) specifies the dash pattern, e.g./D[4 2]
will create 4-point dashes with 2-point gaps;/W 1
— border width (0
will make the border invisible).
