LaTeX document structure
Today we will cover the basic concepts of the LaTeX document structure you'll need to know when creating a book from scratch.
Contents
Subfiles ↩
Once your document grows to a particular size, it could become somewhat inconvenient to navigate the file. I've mentioned the *.sty
files previously, and today we will cover subfiles
1 — a handy way to keep parts of your complex projects separated.
So, let's say you want to have each chapter of your project in its own file. Include the following lines into your main project file:
\usepackage{subfiles}
(before\begin{document}
)\subfile{filename}
(inside thedocument
environment, where "filename" is your chapter file)
If you're using the example project from before, now it will look like this:
example.tex
\documentclass[10pt,twoside,twocolumn,openany]{book}
\usepackage{example}
\usepackage[utf8]{inputenc}
\usepackage{lipsum}
\usepackage{subfiles}
\title{\scshape\LaTeX~Example}
\author{Vladar}
\begin{document}
\maketitle
\subfile{example_sub1}
\subfile{example_sub2}
\end{document}
Naturally, you'll need to create these two new files. To have some contents to demonstrate the features described below, I've added some tables and figures. These will be described in the future blog posts, so just copy-paste it all as is for now. Also, create an img
directory and place a placeholder image into it. I've used this one:
Finally, you need to add these lines into your example.sty
file:
\usepackage{graphicx}
\graphicspath{ {./img/} }
Each subfile should start with this line:
\documentclass[project]{subfiles}
With project
replaced with your project's name (in our case — example
).
example_sub1.tex
\documentclass[example]{subfiles}
\begin{document}
\chapter{First One}
\section{Orcs}
Here's an example of a custom command defined in \verb|example.sty| that formats a monster stat block:
\index{Orcs}
\statblock[d6]{Orcs}{MV 40'; AC 6; HD 1; AB +1; \#AT 1 scimitar (1d8); SV F1; AL C; Int 7; ML 8; XP 10.}{}
\begin{table}[h!]
\centering
\caption{Encountering Orcs}
\vspace{1ex}
\label{table:1}
\begin{tabular}{c|l}
\textbf{d6} & \textbf{Orcs' Reaction} \\
\hline
1--3 & immediate attack \\
4--5 & hostile, ready to attack \\
6 & pretend to be friendly, attack later \\
\end{tabular}
\end{table}
\end{document}
example_sub2.tex
\documentclass[example]{subfiles}
\begin{document}
\chapter{Second One}
\section{Pug Knights}
\begin{table}[h!]
\centering
\caption{Random Encounter}
\vspace{1ex}
\label{table:1}
\begin{tabular}{c|l}
\textbf{d6} & \textbf{Encounter} \\
\hline
1--3 & first pug knight \\
4--5 & second pug knight \\
6 & two pug knights jousting \\
\end{tabular}
\end{table}
\subsection{First Pug Knight}
\begin{figure}[h!]
\index{Pug Knight}
\centering
\includegraphics[width=\linewidth]{pugknight}
\caption{First Pug Knight}
\end{figure}
\clearpage
\subsection{Second Pug Knight}
\begin{figure}[h!]
\index{Pug Knight}
\centering
\scalebox{-1}[1]{\includegraphics[width=\linewidth]{pugknight}}
\caption{Second Pug Knight}
\end{figure}
\clearpage
\index{Lorem ipsum}
\lipsum[1-7]
\end{document}
Now, if you compile your main project file, it will include the contents from both subfiles.
If you use a LaTeX editor, you probably already know what button to press to assemble the PDF. Otherwise, consult your TeX distribution's documentation. For example, if you are using TeX Live2, just run the following command:
pdflatex example.tex
Table of Contents ↩
Now, for the fun part. If you have your document structure in order, creating the table of contents takes a single command:
\tableofcontents
If you want to limit the depth of your ToC, use this command beforehand:
\setcounter{tocdepth}{1}
The number corresponds to the depth level:
- chapter
- section
- subsection
- subsubsection
- paragraph
- subparagraph
We don't have anything deeper than subsection currently, but try to add some and test it. Also, keep in mind, that sometimes you'll need to run the build process twice to see the changes in your ToC.
There are multiple ways to customize the ToC. Here are the most basic ones.
Changing the title
\renewcommand*\contentsname{Table of Contents}
Disabling hyphenation
\hyphenchar\font=-1
\tableofcontents
\hyphenchar\font=`\-
Multiple columns
This is easily done with the multitoc
3 package:
\usepackage[toc,lot,lof]{multitoc}
You can control the number of columns like this:
\renewcommand{\multicolumntoc}{3}
List of Tables and Figures ↩
Similarly to the ToC, you may have a list of tables and figures:
\listoftables
\listoffigures
To be in these lists, your table and figure environments must have captions:
\caption{Name}
Just like the ToC, you can change their titles:
\renewcommand*\listtablename{Tables}
\renewcommand*\listfigurename{Figures}
Or the number of columns (through the multitoc
package):
\renewcommand{\multicolumnlot}{3}
\renewcommand{\multicolumnlof}{3}
Index ↩
Finally, you can have an index (or even multiple ones). I recommend using the imakeidx
4 package for this.
\RequirePackage{imakeidx}
% default index
\makeindex
% another index
\makeindex[name=anotherindex, title={Another Index}]
To add an entry to the index, use the index
command:
\index{Entry}
\index[anotherindex]{Entry}
For more options, check out sophisticated indexing reference.
And to print it all out:
\printindex
\printindex[anotherindex]
To adjust the style, you can use custom style files (options
parameter from imakeidx
) and idxlayout
5 package.
For example, here are the ones similar to Into the Dungeon: Revived:
\usepackage{imakeidx}
\makeindex[options=-s example]
\usepackage[totoc,columns=3,columnsep=1em,font=small,indentunit=1em,rule=0px]{idxlayout}
Add the example.ist
file to your project's directory:
heading_prefix "{\\bfseries\\hfil "
heading_suffix "\\hfil}\\nopagebreak\n"
headings_flag 1
delim_0 "\\dotfill"
delim_1 "\\dotfill"
delim_2 "\\dotfill"
As a homework, I'll leave it to you to discover what each parameter does.
That's all for today. See you next time for more LaTeX goodness!
